A)First Nailer(top)
Maximum dimension of pallet 120x120 cm
Minimum dimension of pallet 80x100 cm
Minimum nailing duration 3 or 5 pieces/ min.
Type of nails loose nail
Three different dimensions of nail
Throwing nail unit PNEUMATIC AND AUTOMATIC
Nailing unit HYDRAULIC
Automation of the machine PLC control.
17 pieces nail gun (number and distances of gun changeable upon request)
Total electricity 21,45 Kw
Width: 214 cm length:650 cm height:320 cm
B) Turner unit
Total electricity capacity 2,2 Kw
Width: 176 cm length:350 cm height:94 cm
Working system mechanic
C) Second nailer (bottom)
Maximum dimension of pallet 150x200 cm
Minimum dimension of pallet 80x100 cm
Minimum nailing duration 3 or 5 pieces/ min.
Type of nails cast nail
Three different dimensions of nail
Throwing nail unit PNEUMATIC AND AUTOMATIC
Nailing unit HYDRAULIC
Automation of the machine PLC control.
9 pieces nail gun (numbers and distances of gun changeable upon request)
Total electricity 21,45 Kw
Width: 214 cm length: 650 cm height: 240 cm
D)Turner unit
-Total electricity capacity: 1 Kw
-Width:248 cm length:440 cm height:94 cm
-Working system: Mechanic
E)Pallet Marking (Branding)
-Section to branding 6 blocks of the pallet at the same time.
-Brand heating system: Electrical resistance
-Brand press system: Pneumatic
-Brand cachet: chrome or bronze
-Electricity power of resistance : 0,6 Kw (6 pcs.)
F)Pallet Corner Cutting
-Section to cutting the cormers
-Diameter of saw : 250mm
-Saw movement: Pneumatic piston
-Saw motor power: 2,2 Kw (4 pcs.)
G)Turner unit
-Total electricity capacity: 1 Kw
-Width:176 cm length:350 cm height:94 cm
-Working system: Mechanic
E)Pallet Chamfering
-Section to milling inlet & outlet edges of the bottom boards as
45 ◦
-6 pcs. special chamfering blade
-Motor power: 2,2 Kw (6 pcs.)
-Pallet movement power: 0,75 Kw
-Total electric power: 33, 55 Kw
-Dimensions of Corner cutting, Marking and Chamfering units;
-Width: 240 cm Length: 650 cm Height: 150 cm
-Weight: 2350 kg
G)Turner unit
-Total electricity capacity: 1 Kw
-Width:176 cm length:350 cm height:94 cm
-Working system: Mechanic
H)Automatic Stacker
-Section to stacking the pallets as successively or telescopic
-Stacker system : 2,2kw
-Max. Stacking: 40 pcs.
-Width: 185 cm Length: 200 cm Height: 150 cm
-Weight: 950 kg
I)Unloading Conveyor
-Motor power: 0,75 Kw
